Garrett GT3076R (GT30R) Turbochargers
PT Turbo lists 4 complete turbochargers, 1 supercore, 7 CHRA cartridges and 6 other parts for the Garrett GT3076R, with complete turbos from $1,442 to $1,695. Each listing is one exact part number, so match the number on your turbo’s data plate before ordering, or call (909) 824-1020 and we will match it for you.
Categories and filters
What the Garrett GT3076R is
The GT3076R is a Garrett GT30-series ball-bearing turbo with a water-cooled CHRA. Garrett rates it at 310 to 525 horsepower; its current page gives engines of 2.0 to 3.5 liters, while its 2015 catalog said 1.8 to 3.0 liters. It has a 57 / 76 mm, 56 trim compressor wheel in a 0.60 A/R housing and a 60 / 55 mm, 84 trim turbine wheel (supercore 836028-5003S), and uses the same GT30 turbine kits as the GTX3071R, interchangeable with GT and GTX Gen I and Gen II 30-series supercores.
This page lists complete GT3076R turbos, a supercore, CHRAs and housings. Garrett’s own guidance on turbine housings: a smaller A/R gives quicker boost response and more turbine power at low engine speed; a larger A/R lets the wheel flow more, with lower back pressure and more power at high engine speed.
Sources: Garrett GT3076R · Garrett catalog volume 5 (2015, archived) · Garrett: Turbine Housings 101
About the Garrett GT3076R
- In the catalog
- 4 complete turbochargers, 1 supercore, 7 CHRA cartridges and 6 other parts
- Complete turbo price
- $1,442 to $1,695
- Shop by category
- Garrett Performance Turbos·GT / GTX Ball Bearing·CHRA·CHRA - Garrett Ball Bearing
GT3076R specifications
Wheel sizes are inducer / exducer, taken from the specification published for each part number. The turbine housing sizes are the ones on the listings above; the same turbo is sold with several.
| Model | Compressor wheel | Turbine wheel | Compressor housing | Turbine housing A/R | Listings | From |
|---|---|---|---|---|---|---|
| GT3076R | 57 / 76 mm, 56 trim | 60 / 55 mm, 84 trim | 0.60 A/R | 0.63, 0.82 | 3 | $1,695 |
