Built for enthusiasts chasing serious top-end power without sacrificing drivability, the Garrett GT3582R pairs a ball bearing center section with an anti-surge compressor housing and a T4 undivided turbine housing for broad, usable boost across the RPM range. This turbo is the go-to choice for high-horsepower LSX and other performance builds that demand a proven, high-flow platform. Whether you’re building a street car with serious headroom or a dedicated track machine, the GT3582R delivers the flow capacity to back it up.

Specifications

• Compressor Wheel Inducer: 61.4mm
• Compressor Wheel Exducer: 82mm
• Compressor Wheel Trim: 56
• Compressor Housing A/R: 0.70
• Compressor Housing Frame: T04S
• Compressor Inlet: 4″
• Compressor Outlet: 2.5″
• Compressor Housing Type: Anti-Surge
• Turbine Wheel Inducer: 68mm
• Turbine Wheel Exducer: 62.3mm
• Turbine Wheel Trim: 84
• Turbine Housing A/R: 0.63
• Turbine Housing Inlet: T4 Undivided
• Turbine Housing Outlet: 3″ GT V-Band
• Bearing Type: Ball Bearing
• HP Capacity: 650HP+ potential flow
• Also Known As: GT35R, GT35/GT40R

Performance & Application

The GT3582R is engineered for builds targeting 650HP and beyond, making it a strong fit for GM LSX platforms and other high-output performance applications. Its ball bearing core reduces spool lag and sharpens throttle response compared to journal bearing designs, while the anti-surge compressor housing extends the usable map for stable boost delivery under varying load conditions. The 0.63 A/R T4 undivided turbine housing with a 3″ GT V-Band outlet is tuned to balance quick spool with strong top-end flow. This combination makes the GT3582R well suited to enthusiasts building serious street or track setups who need both response and high-horsepower headroom.

Frequently Asked Questions

What HP can the GT3582R support?

The GT3582R supports 650HP+ potential flow.

Is this a ball bearing or journal bearing turbo?

The GT3582R is a Garrett ball bearing turbocharger.

What is the A/R ratio on the turbine housing?

The turbine housing uses a 0.63 A/R with a T4 undivided inlet.

What does “GT35R” or “GT35/GT40R” refer to?

These are alternate names for the Garrett GT3582R turbocharger.

For builds demanding proven ball bearing performance with high-horsepower flow capacity, the GT3582R remains a benchmark choice engineered to deliver.
