GT3582R Turbo with T04S Frame 4" in / 2.5" out Anti-Surge, .63 A/R T4 Undivided 3" GT VB
GT3582R Turbo with T04S Frame 4" in / 2.5" out Anti-Surge, .63 A/R T4 Undivided 3" GT VB
GT3582R Turbo with T04S Frame 4" in / 2.5" out Anti-Surge, .63 A/R T4 Undivided 3" GT VB
GT3582R Turbo with T04S Frame 4" in / 2.5" out Anti-Surge, .63 A/R T4 Undivided 3" GT VB
GT3582R Turbo with T04S Frame 4" in / 2.5" out Anti-Surge, .63 A/R T4 Undivided 3" GT VB
GT3582R Turbo with T04S Frame 4" in / 2.5" out Anti-Surge, .63 A/R T4 Undivided 3" GT VB

GT3582R Turbo with T04S Frame 4″ in / 2.5″ out Anti-Surge, .63 A/R T4 Undivided 3″ GT VB

$1,795.00

Ball-bearing GT3582R: 650HP+ potential with 61.4/82mm compressor (0.70 A/R T04S), 68/62.3mm turbine (0.63 A/R T4 undivided), and 3″ GT V-Band outlet. Anti-surge capable with 56/84 trim wheels.

Specifications

  • Compressor Wheel Inducer: 61.4mm
  • Compressor Wheel Exducer: 82mm
  • Compressor Wheel Trim: 56
  • Compressor Housing A/R: 0.70
  • Compressor Housing Frame: T04S
  • Compressor Inlet: 4″
  • Compressor Outlet: 2.5″
  • Compressor Housing Type: Anti-Surge
  • Turbine Wheel Inducer: 68mm
  • Turbine Wheel Exducer: 62.3mm
  • Turbine Wheel Trim: 84
  • Turbine Housing A/R: 0.63
  • Turbine Housing Inlet: T4 Undivided
  • Turbine Housing Outlet: 3″ GT V-Band
  • Bearing Type: Ball Bearing
  • HP Capacity: 650HP+ potential flow
  • Also Known As: GT35R, GT35/GT40R
Weight 20 lbs
