The Garrett Supercore G-XRace GXR47-76 is a purpose-built core assembly for enthusiasts and builders chasing serious top-end power from the GX-Race47 platform. Designed as the foundation of a complete turbo unit, it gives tuners and shop builders the flexibility to pair it with the turbine housing that matches their specific power and packaging goals. This is the choice for those building a custom G-Series-based turbo system from the ground up rather than buying an off-the-shelf complete unit.
Specifications
- Compressor Wheel Inducer: 76.6mm
- Compressor Wheel Exducer: 120mm (123mm extended tip)
- Compressor Housing A/R: 0.85
- Turbine Wheel Inducer: 93mm
- Turbine Wheel Exducer: 88mm
- Garrett P/N: 953234-5006S
Performance & Application
This Supercore is engineered for builders assembling a complete G-XRace47 turbo system and requires a turbine housing to be added in order to function as a finished turbo unit. Because it shares turbine housing compatibility with the G-Series G47 turbo, builders have proven housing options available when configuring their setup. This core is best suited for high-output, custom-spec builds where the end user wants control over turbine housing selection to dial in the exact spool and flow characteristics their application demands.
Compatibility & Fitment
- Uses the same turbine housing as the Garrett G-Series G47 turbo
Frequently Asked Questions
- Does this Supercore include a turbine housing?
- No. A turbine housing of your choice must be added to this Supercore in order to complete a full turbo unit.
- What turbine housing is compatible with
