The Garrett GEN2 GTX2860R is a purpose-built performance turbocharger for enthusiasts chasing serious power without sacrificing the responsiveness of a properly sized compressor and turbine combination. Featuring an advanced billet compressor wheel and dual ball bearing core, this GEN2 platform is engineered for builders who demand both quick spool and a strong top-end pull. It’s the turbo of choice for those upgrading a factory turbo system or building a high-response setup on a compact engine bay.
Specifications
- Compressor Wheel Inducer: 46mm
- Compressor Wheel Exducer: 60mm
- Compressor Wheel Trim: 58
- Compressor Housing A/R: 0.60
- Turbine Wheel Inducer: 54mm
- Turbine Wheel Exducer: 47mm
- Turbine Wheel Trim: 76
- Turbine Housing A/R: .86
- Bearing Type: Dual Ball Bearing
- Compressor Inlet: T25
- Compressor Outlet: 5 Bolt (GT28 Style)
- Turbine Housing Design: Internal Wastegate
- HP Capacity: 475HP
- Optional Housing: GT2554R Compact Frame Compressor Housing
Performance & Application
Built around the GEN2 billet compressor wheel, this GTX2860R is designed to support up to 475HP while maintaining the fast-spooling characteristics enthusiasts expect from the GTX line. The .86 A/R internal wastegate turbine housing balances quick response with sufficient flow for sustained high-output runs, making it well suited for street and track builds alike. For those prioritizing an even tighter packaging solution, an optional GT2554R compact frame compressor housing is available. This turbocharger is ideal for enthusiasts seeking a strong balance of low-end response and high-end power delivery.
Compatibility & Fitment
- Nissan VQ35/37 platforms
Frequently Asked Questions
- What HP can the GTX2860R support?
- The GEN2 GTX2860R’s advanced billet compressor wheel is capable of supporting up to 475HP.
- Is this a ball bearing or journal bearing turbo?
- This turbocharger uses a dual ball bearing design.
- What turbine housing A/R and design does this turbo use?
- It comes with a .86 A/R turbine housing featuring an internal wastegate design; the wastegate actuator and bracket are sold separately.
- What inlet and outlet configuration does this turbo have?
- The turbocharger features a T25 inlet and a 5 bolt, GT28-style outlet.
For builders who need a proven GEN2 platform capable of supporting serious horsepower while retaining sharp throttle response, the Garrett GTX2860R with the .86 A/R internal wastegate T25 turbine housing delivers a dependable, performance-focused foundation for your build.
