Garrett Supercore - G-Series II G35-990 Reverse Rotation, P/N: 934126-5001S

Garrett Supercore – G-Series II G35-990 Reverse Rotation, P/N: 934126-5001S

$2,391.76

G35-990 reverse rotation (P/N 934126-5001S): up to 10% higher compressor flow than Gen I with new aero technology for increased efficiency at high RPM. Features Mar-M turbine wheel rated to 1050°C, stainless steel housing, and direct Gen I upgrade compatibility via complete unit, supercore, or CHRA options.

Specifications

  • Rotation: Reverse Rotation
  • Turbine Wheel Material: Mar-M alloy
  • Turbine Wheel Temperature Rating: Up to 1050° C

Wheels and rating

  • Compressor wheel: 62 mm inducer, 76 mm exducer, 65 trim
  • Compressor housing: 0.72 A/R
  • Turbine wheel: 68 mm inducer, 62 mm exducer, 84 trim
  • Garrett’s rating: 550 to 990 hp, for engines of 2.0 to 5.5 liters

Figures from Garrett’s G-Series II product guide for part number 934126-5001S.

Downloads

Weight 20 lbs
