The Garrett GTX4508R-C brings full GTX4508R internals into a compact GT42-style external footprint, giving serious builders massive top-end power potential without demanding a larger turbo housing package. Built for high-boost, high-horsepower applications, this unit is engineered for enthusiasts and race teams who need drop-in performance without re-engineering their turbo system layout. If your build demands big power in a proven, compact frame, this is the configuration to run.
Specifications
- Compressor Wheel Exducer: 108.0mm
- Compressor Wheel Inducer: 79.8mm
- Compressor Wheel Trim: 55 trim
- Compressor Housing A/R: .69 A/R
- Compressor Housing Style: Compact GT42 style
- Turbine Wheel: 87.0mm
- Turbine Wheel Trim: 85 trim
- Turbine Housing A/R: 1.16 A/R
- Turbine Housing Construction: TiAL Stainless V-Band
- Other Turbine Housing A/R Options: 1.01, 1.15, 1.28, 1.44 A/R
- Bearing Type: Ball bearing (GTX-R series)
- Frame Size: GT42 frame (compact)
- HP Capacity: 1400HP
- Garrett P/N: 800270-5001S
- Also Known As: GTX4508R-C
- Alternate P/N: 451888-0045
Performance & Application
This configuration is purpose-built for platforms that need GT42-level output packaged into a more compact compressor and turbine housing arrangement, making it ideal for engine bays and setups where space is at a premium but big horsepower is still the goal. With full GTX4508R internals, this turbo is engineered to flow more air and handle significantly more boost than earlier generation units in this size class. Expect strong high-RPM power delivery suited to dedicated race builds and high-output street/strip applications. The stainless V-band turbine housing and TiAL construction support fast, reliable installation into modern V-band turbo manifold and downpipe setups.
Frequently Asked Questions
- What HP can the GTX4508R-C support?
- This unit is capable of supporting up to 1400HP.
- Is the GTX4
