The Garrett GTX4202R is a large-frame, ball bearing turbocharger built for serious high-horsepower applications where response and top-end flow both matter. Designed with a high-flowing compressor housing and a ported shroud for anti-surge performance, this turbo is engineered for enthusiasts and racers pushing well beyond stock power levels. It’s the right choice for builders who demand a turbo capable of extreme output without sacrificing usability.
Specifications
- Compressor Wheel Inducer: 75.8mm
- Compressor Wheel Exducer: 102.3mm
- Compressor Wheel Trim: 55
- Compressor Housing A/R: 60
- Compressor Housing Frame: GT42R
- Compressor Inlet: 5″
- Compressor Outlet: V-Band, 4.5″ OD (3.5″ ID)
- Turbine Wheel Inducer: 82mm
- Turbine Wheel Exducer: 75.1mm
- Turbine Wheel Trim: 84 trim
- Turbine Housing A/R: 1.44
- Turbine Housing Inlet: V-Band
- Turbine Housing Outlet: 4″ V-Band
- Bearing Type: Ball Bearing
- HP Capacity: Supports over 1,100HP
- Garrett P/N: GTX4202R
Performance & Application
Built on Garrett’s large GT42R frame, the GTX4202R is designed to support extreme horsepower levels while maintaining strong compressor efficiency across a wide operating range. The ported shroud compressor housing helps resist surge at the edges of the map, allowing this turbo to deliver both response and high-end flow capability. This unit is suited for builders targeting serious power goals who need a compressor and turbine combination capable of handling significant boost and airflow demands. The V-band inlet and outlet configuration on both the compressor and turbine housings supports clean, efficient plumbing for high-performance turbo system builds.
Frequently Asked Questions
- What HP can the GTX4202R support?
- The GTX4202R supports over 1,100HP.
- Is the GTX4202R a ball bearing or journal bearing turbo?
- The GTX4202R is a ball bearing turbocharger.
- What is the turbine housing A/R ratio?
- The turbine housing has a 1.44 A/R ratio with a V-Band inlet and 4″ V-Band outlet.
- What compressor housing configuration does the GTX4202R use?
- The compressor housing features a 60 A/R on the GT42R frame, with a 5″ inlet and a V-Band outlet measuring 4.5″ OD (3.5″ ID), including a built-in ported shroud for anti-surge performance.
For builders chasing four-figure horsepower with a turbo engineered for both flow and control, the Garrett GTX4202R delivers the large-frame ball bearing performance needed to get there.
