The Garrett GTX4202R is a large-frame ball bearing turbocharger built for enthusiasts chasing serious top-end power without sacrificing usability. Designed around Garrett’s proven GTX-R platform, it delivers the durability and response demanded by high-horsepower street and race applications. This is the turbo for builders who need massive airflow potential backed by Garrett engineering.

Specifications

• Compressor Wheel Inducer: 75.8mm
• Compressor Wheel Exducer: 102.3mm
• Compressor Wheel Trim: 55
• Compressor Housing A/R: 60
• Compressor Housing Frame: GT42R Frame
• Compressor Inlet: 5″ Inlet
• Compressor Outlet: V-Band, 4.5″ OD (3.5″ ID)
• Turbine Wheel Inducer: 82mm
• Turbine Wheel Exducer: 75.1mm
• Turbine Wheel Trim: 84 trim
• Turbine Housing: TiAL Stainless Steel, 1.15 A/R
• Turbine Housing Inlet: V-Band
• Turbine Housing Outlet: 4″ V-Band
• Bearing Type: Ball Bearing
• HP Capacity: Supports over 1,100HP
• Garrett P/N: GTX4202R

Performance & Application

Built on Garrett’s large-frame GT42R platform, the GTX4202R is engineered for builders targeting massive power output on high-performance engine platforms. The ball bearing core provides sharper transient response and improved spool characteristics compared to traditional journal bearing designs, while the high-flowing compressor housing and TiAL stainless steel turbine housing support sustained top-end power delivery. The built-in ported shroud design improves compressor stability and resists surge under aggressive boost conditions. This turbo is best suited for high-horsepower builds where both flow capacity and bearing durability are critical.

Frequently Asked Questions

What HP can the GTX4202R support?

The GTX4202R supports over 1,100HP.

Is the GTX4202R a ball bearing or journal bearing turbo?

The GTX4202R is a ball bearing turbocharger.

What is the turbine housing A/R ratio?

The turbine housing is a TiAL Stainless Steel unit with a 1.15 A/R ratio, featuring a V-Band inlet and 4″ V-Band outlet.

What is the compressor housing A/R ratio?

The compressor housing features a 60 A/R on the GT42R frame, with a 5″ inlet and V-Band outlet.

For builders demanding uncompromising airflow, ball bearing response, and proven Garrett durability at four-figure horsepower levels, the GTX4202R stands as a definitive choice.
