The Garrett GTX2867R Gen2 in Black represents a serious step up for builders who demand rapid spool without sacrificing top-end capability. Finished with a billet Gen2 compressor wheel and a stainless steel TiAL V-band turbine housing, this turbo is engineered for enthusiasts pushing serious power out of a compact frame. It’s the choice for those who want proven Garrett engineering paired with premium V-band plumbing for a cleaner, more efficient install.

Specifications

• Compressor Wheel Inducer: 50mm
• Compressor Wheel Exducer: 67mm
• Compressor Wheel Trim: 55
• Compressor Housing A/R: 0.60
• Turbine Wheel Inducer: 54mm
• Turbine Wheel Exducer: 47mm
• Turbine Wheel Trim: 76
• Turbine Housing A/R: .64
• Turbine Housing Material: Stainless Steel
• Turbine Housing Inlet: V-Band
• Turbine Housing Outlet: V-Band
• Bearing Type: Dual Ball Bearing
• HP Capacity: 550HP
• Finish: Black

Performance & Application

Built around Garrett’s advanced Gen2 billet compressor wheel technology, this GTX2867R is designed for enthusiasts seeking quick throttle response combined with the ability to support serious horsepower. The dual ball bearing center cartridge delivers reduced spool lag compared to journal bearing designs, making it well-suited for builds where responsiveness matters as much as outright power. The TiAL stainless V-band turbine housing improves exhaust flow and simplifies installation on setups using V-band exhaust manifolds and downpipes. This turbo is capable of supporting up to 550HP, making it a strong fit for performance-focused street and track applications.

Frequently Asked Questions

What HP can the GTX2867R support?

This Gen2 billet compressor wheel is capable of supporting up to 550HP.

Is this a ball bearing or journal bearing turbo?

This GTX2867R is a dual ball bearing turbocharger.

What turbine housing inlet/outlet does this use?

It features a TiAL Stainless Steel turbine housing with a V-Band inlet and V-Band outlet.

What is the turbine housing A/R ratio?

The turbine housing has a .64 A/R ratio.

For builders who want Garrett Gen2 billet compressor technology backed by a premium stainless V-band turbine housing, this GTX2867R delivers the response and capability needed to build with confidence.
